Online Lateral
Online Lateral
"Khedut” Lateral pipes are produced from 100% leaner law density polyethylene vergin materail. It also posses/ the compare standard mark as per IS 12786. “Khedut”.
LLDPE tubings (pipes) are used as micro irrigation laterals on which sprayers, drippers or immiters are mounted directly or by means of fittings. “Khedut” LLDPE tubings are available in all sizes i.e. 12mm., 16mm., 20mm., 25mm., & 32mm. Classification of Pipe
“Khedut” LLDPE tubings are classified by pressure rating (working pressure) at 27’C as per IS- 12786
| Class of Pipe | Working Pressure |
|---|---|
| Class I | 0.20 MPa. |
| Class II | 0.25 MPa. |
| Outside Diameter | Class 1 | Class 2 | ||
|---|---|---|---|---|
| (0.20 MPs.) | (0.25 MPs.) | |||
| Min. | Max. | Min. | Max. | |
| 12 | 0.6 | 0.8 | 0.9 | 1.1 |
| 16 | 0.8 | 1.0 | 1.1 | 1.3 |
| 20 | 0.9 | 1.1 | 1.3 | 1.4 |
| 25 | 1.2 | 1.6 | 1.7 | 2.0 |
| 32 | 1.5 | 1.9 | 2.0 | 2.4 |
| Property | Value | Unit |
|---|---|---|
| Tensile Strength | 12.5 | MPA |
| Elongation | 500 | % |
| Carbon Black Content | 2.5 (+-0.5) | % |
| Carbon Black Dispersion | Satisfactory | — |
| ESCR | O.K. | — |
“Khedut” LLDPE tubings are resistance to most of the mineral acids, alkalis, sults, oxidizing agents organic acids, oils, solvents and gases etc.
Being a client-centric organization and backed by dexterous professionals we are offering high quality range of Online Drip Lateral Pipe. Widely used to connect drip irrigation systems they are fabricated using high quality materials and latest technology as per industry norms. We ensure quality on various parameters till final delivery and offer a defect free range at attractive market prices.drip
